Phoenix Contact (1729144) Wire-To-Board Terminal Block, 5.08 mm, 4 Ways

Wire-To-Board Terminal Block, 5.08 mm, 4 Ways, 26 AWG, 16 AWG, 1.5 mm², ScrewProduct OverviewThe 1729144 is a 4-position green PCB Terminal Block with tin-plated soldercontacts, a polyamide insulator and the M3 screw connection. This MKDSN 1,5/4-5,08 terminal block has fully developed contact geometries and surfaces. Ithas compact housing dimensions and low design height. It accepts 26 to 16AWGwire range.Space-saving and safeSingle-row type with horizontal connection direction6mm Stripping lengthUL94V-0 Flammability ratingApplicationsIndustrialProduct InformationPitch Spacing: 5.08mmWire Size AWG Min: 26AWGWire Size AWG Max: 16AWGConductor Area CSA: 1.5mm²Wire Connection Method: ScrewRated Current: 13.5ARated Voltage: 250VBlock Orientation: Through Hole Right AngleProduct Range: MKDSN
