RF Wideband Amplifier LNA 0.1M-2G Gain 60dB Two-stage Amplification

New 20 available
R569.00
Shipping
R35.00 Standard shipping using one of our trusted couriers applies to most areas in South Africa. Some areas may attract a R30.00 surcharge. This will be calculated at checkout if applicable.
Check my rate
The seller has indicated that they will usually have this item ready to ship within 12 business days. Shipping time depends on your delivery address. The most accurate delivery time will be calculated at checkout, but in general, the following shipping times apply:

Standard Delivery
Main centres:  1-3 business days
Regional areas: 3-4 business days
Remote areas: 3-5 business days
Seller
Buyer protection
Returns
Replacement Guarantee: 7 Days: We stand by this guarantee
Get it now, pay later

Product details

Condition
New
Location
International
Bob Shop ID
654106041
Description:

Using two cascaded, with low noise, high gain (60dB) features, suitable for weak signal detection LNA low noise.

Feature:

Working frequency: 0.01-2000MHz Power gain: 60dB @ 500M Noise figure NF: 2dB @ 300M Maximum output power: +10 dBm (10mW) @ 1dB compression point Working current: 70mA (12V) Supply voltage: 12V recommended, (9-15V) System Impedance: 50 ohms Higher gain flatness when working within 500M

Package included:

1 xRF Wideband Amplifier
