SRNE 8KVA 16000W Off Grid Hybrid Solar Inverter 48V Inverter (180A MPPT)

SRNE 8Kva 16000W Off Grid Hybrid Solar Inverter 48V Inverter (180A MPPT)

Efficient

• Dual MPPT with up to 99.9% efficiency
• Up to 22A PV input current perfect for high power modules

Reliable

• Outputs high quality pure sine wave AC power
• 8-10kW load power to meet the needs of most households

User-friendly

• Industrial design with a modern aesthetic look
• Easy to install and simple to use

Safety

• 360 degrees of security from hardware to software

• EU and North American safety approvals

All-in-one

• Solar Charger Controller up to 200A charging current
• Support for Li-ion battery BMS communication

Intelligent

• Exclusive Li-ion battery BMS dual activation
• Time-slot function to save cost with peak-valley tariff

Rated Output Power: 8,000W
Max.Peak Power: 16,000W
Rated Output Voltage: 230VacL1/N/PE single-phase
Load Capacity of Motors: 5HP
Rated AC Frequency: 50/60Hz
Waveform: Pure Sine Wave
Switch Time: 10mstypical
Battery Type: Li-ion / Lead-Acid / User Defined
Rated Battery Voltage: 48Vdc
Voltage Range: 40-60Vdc
Max.MPPT Charging Current: 200A
Max.Mains/Generator Charging Current: 100A
Max.Hybrid Charging Current: 180A


PV INPUT
Num. of MPP Trackers: 2
Max.PV array power: 11,000W
Max.input current: 22/22A
Max.Voltage of Open Circuit: 500Vdc
MPPT Voltage Range: 125-425Vdc


MAINS / GENERATOR INPUT
Input Voltage Range: 90-270Vac
Frequency Range: 50/60Hz
Bypass Overload Current: 32A


EFFICIENCY
MPPT Tracking Efficiency: 99.9%
Max. Battery Inverter Efficiency: 92%


GENERAL

Dimensions
620*435*130mm2*1.4*0.4ft
Weight: 20kg44lb
Protection Degree: IP20Indoor Only
Operating Temperature Range: -15~55,>45 derated5~131>113 derated
Noise: <60dB
Cooling Method: Internal Fan

Warranty: 2 Years

COMMUNICATION
Embedded Interfaces: RS485 / CAN / USB / Dry contact
External Modules Optional: Wi-Fi / GPRS

• 2-Years Warranty
• Warranties: All inverters and batteries must be installed by a qualified electrical wireman or Master electrician with a valid registration with the Department of Labor. A valid electrical certificate of compliance (COC) must be issued once installed, specific to the installation of the backup or solar system. The installation must be compliant with SANS 10142 and ALL its parts. Any warranty claim submitted without installation photos, a valid COC, and proof of a qualified wireman/master electrician installing the unit, can be rejected and will render the warranty claim null at the void.
