SUNSUNK 5KW HYBRID INVERTER
Sunsynk 5KW Hybrid Inverter + 1x Volta 5.12kWh (Stage 1 / NEW GEN) Lithium Battery / Solar Power System
Product Overview
The Sunsynk 5KW Hybrid Inverter, paired with the Volta 5.12kWh Lithium Battery, delivers a high-performance and scalable solar energy storage solution for homes, businesses, and off-grid applications.
This system offers seamless power management, efficient solar energy utilization, and intelligent battery backup, ensuring uninterrupted electricity during load shedding or power outages. With advanced MPPT technology, WiFi-enabled monitoring, and parallel expansion capabilities, this solution is designed for reliable, long-term energy independence.
Key Features
Sunsynk 5KW Hybrid Inverter
Optimized Solar Power Utilization Reduces grid reliance by up to 80%, lowering energy costs.
Dual MPPT Technology Maximizes solar efficiency with a 97.6% conversion rate.
Seamless Grid & Off-Grid Transition Automatically switches within 5ms for uninterrupted power supply.
Multiple Power Sources Supports solar panels, grid power, and wind turbines.
Expandable System Can be paralleled with up to 16 inverters for increased power capacity.
Smart Battery Management System (BMS) Compatible with lithium-ion and lead-acid batteries.
User-Friendly LCD & App Control Monitor system performance remotely via WiFi & mobile app.
Configurable Charging & Discharging Schedules Allows smart energy management for cost savings.
Technical Specifications
Sunsynk 5KW Hybrid Inverter
- Type: Hybrid (Grid-Tied & Off-Grid)
- Rated Power: 5,000W / 5KVA
- Surge Power: 10,000VA (10 sec.)
- Efficiency: 97.6% (Maximum)
- Waveform: Pure Sine Wave
- AC Voltage Regulation: 240V ±5%
- Transfer Time: 5ms (Seamless grid-to-off-grid switching)
- MPPT Solar Charge Controller:
- Max PV Input Power: 6,500W
- MPPT Voltage Range: 125V - 425V DC
- Max PV Open Circuit Voltage: 500V DC
- Max Solar Charge Current: 120A
- AC Charging Capacity:
- Charge Current: 80A
- Input Voltage: 230V AC
- Selectable Voltage Range: 195V - 253V AC
- Battery Compatibility:
- Supports Lithium-Ion & Lead-Acid Batteries
- Voltage Range: 40V - 60V
- Max Charge/Discharge Current: 120A
- Connectivity & Monitoring:
- WiFi & GSM Remote Monitoring
- RS485 & CAN Communication for BMS Integration
- Dimensions & Weight:
- Size: 580 x 330 x 208 mm
- Weight: 20.5 kg
- Installation: Wall-Mounted (IP65 Rated Suitable for Indoor & Outdoor Use)
- Warranty: 10Years
Volta Stage 1 New Gen 5.12kWh Lithium Battery (51.2V 100Ah)
High-Performance Lithium Storage 5.12kWh capacity with a lifespan of over 6,000 cycles.
Scalability Expand storage by connecting up to 8 batteries in parallel, reaching 40kWh capacity.
Fast Charging & High Discharge Rate Supports 100A continuous discharge for high-power loads.
Extended Battery Life Designed for 10+ years of operation.
Flexible Installation Wall-mounted or floor-standing for space-saving solutions.
Advanced Battery Management System (BMS) Enhances safety, efficiency, and battery longevity.
Technical Specifications
Volta Stage 1 New Gen 5.12kWh Lithium Battery
- Battery Type: Lithium Iron Phosphate (LiFePO4)
- Nominal Voltage: 51.2V
- Total Energy Capacity: 5.12kWh
- Usable Capacity: 4.6kWh
- Depth of Discharge (DOD): 80%
- Cycle Life: 6,000+ Cycles @ 25°C
- Nominal Capacity: 100Ah
- Charge Voltage: 56V DC
- Discharge Cut-Off Voltage: 44.8V DC
- Max Continuous Charge/Discharge Current: 100A
- Operating Temperature Range: -20°C to 55°C
- Installation: Wall-Mount or Floor-Standing
- Communication: CAN / RS485
- Battery Warranty: 10 Years
Package Contents
1x Sunsynk 5KW Hybrid Inverter (WiFi Dongle Included)
1x Volta 5.12kWh Lithium Battery (51.2V 100Ah LiFePO4)
1x Set of Battery Cables & Mounts
1x Ethernet Communication Cable
1x User Manual
Installation & Warranty Guidelines
- Installation Requirement: Must be installed by a certified electrician.
- Certificate of Compliance (COC): Required for warranty validation.
- Warranty Coverage:
- Inverter Warranty: 10 Years
- Battery Warranty: 10 Years
- Warranty Claims:
- Must include installation photos, valid COC, and proof of installation by...
