Extends dual-band Wi-Fi across your home to eliminate Wi-Fi dead zones.
Creates a Mesh network by connecting to a TP-Link OneMesh router for seamless whole-home coverage.
Operates over both the 2.4 GHz band (300 Mbps) and 5 GHz band (867 Mbps)*1 for more stable wireless experience.
Smart signal indicator helps to find the best location for optimal Wi-Fi coverage by showing the signal strength.
Push the WPS button to easily set up a Mesh network you can uniformly manage from the Tether app or Web UI.
Works with any Wi-Fi router or wireless access point.*2
HARDWARE FEATURES
Standards and Protocols IEEE802.11ac, IEEE 802.11n, IEEE 802.11g, IEEE 802.11a, IEEE 802.11b
Plug Type EU, UK, US, AU
Ports -
Button WPS Button, Reset Button
Input Power 100-240V~50/60Hz
Power Consumption 7.3W?max power consumption?
Dimensions ( W x D x H ) 4.9 x 2.7 x 2.0 in (124 x 69 x 52 mm)
Antenna 2 Internal Antennas
WIRELESS FEATURES
Wireless Standards IEEE 802.11a/n/ac 5GHz, IEEE 802.11b/g/n 2.4GHz
Frequency 2.4GHz & 5GHz(11ac)
Signal Rate 5 GHz:Up to 867 Mbps
2.4 GHz:Up to 300 Mpbs
Working Modes Range Extender
Reception Sensitivity 5GHz?
11a 6Mbps:-91dBm@10% PER
11a 54Mbps: -74dBm@10% PER
11ac HT20 mcs8: -68dBm@10% PER
11ac HT40 mcs9: -63dBm@10% PER
11ac HT80 mcs9: -59dBm@10% PER
2.4GHz
11g 54M: -79dBm@10% PER
11n HT20 mcs7: -77dBm@10% PER
11n HT40 mcs7: -74dBm@10% PER
Wireless Modes
Wireless Functions Wireless Statistic
Concurrent Mode boost both 2.4G/5G Wi-Fi band
Access Control
LED Control
Domain Login Function
Wireless Security 64/128-bit WEP
WPA-PSK / WPA2-PSK
Transmission Power Mesh Technology EasyMesh
OTHERS
Certification CE, FCC, RoHS
Package Contents ? AC1200 OneMesh Wi-Fi Range Extender RE300
? Quick Installation Guide
Box Dimensions (W X D X H) 6.2 x 4.0 x 3.5 in. (156.5 x 101.5 x 89 mm)
System Requirements Microsoft® Windows® 98SE, NT, 2000, XP, Vista or Windows 7, 8, 10, Mac® OS, NetWare®, UNIX® or Linux.
Environment Operating Temperature: 0°C~40°C (32°F~104°F)
Storage Temperature: -40°C~70°C (-40°F~158°F)
Operating Humidity: 10%~90% non-condensing
Storage Humidity: 5%~90% non-condensing
*1. Maximum wireless signal rates are the physical rates derived from IEEE Standard 802.11 specifications. Actual wireless data throughput and wireless coverage are not guaranteed and will vary as a result of 1) environmental factors, including building materials, physical objects, and obstacles, 2) network conditions, including local interference, volume and density of traffic, product location, network complexity, and network overhead, and 3) client limitations, including rated performance, location, connection quality, and client condition.
*2. The product may not be compatible with routers or gateways with firmware that has been altered, is based on open source programs, or is non-standard or outdated.
*3. Smart Roaming is designed for devices that support the 802.11k/v standard.
