AC1750 Dual Band Wi-Fi - Simultaneous 450Mbps on 2.4GHz + 1300Mbps on 5GHz
Three Antennas - Three adjustable external antennas provide optimal Wi-Fi coverage and reliable connections
Gigabit Ethernet port - Act as a wireless adapter to connect a wired device to your network at Gigabit speed
Intelligent Signal Light - Help to find the best location for optimal Wi-Fi coverage by showing the signal strength
AP Mode - Create a new Wi-Fi access point to enhance your wired network with Wi-Fi capability
TP-Link Tether App - Easily access and manage your network using any iOS or Android mobile device
Ultimate Compatibility - Extend the range of any Wi-Fi router or wireless access point
WIRELESS
Working Modes Range Extender/Access Point
HARDWARE FEATURES
Standards and Protocols IEEE802.11ac, IEEE 802.11n, IEEE 802.11g, IEEE 802.11b
Plug Type EU, UK, US, AU, KR, JP
Interface 1 x 10/100/1000M Ethernet Port (RJ45)
Ports 1 Gigabit Ethernet Port
Button WPS Button, Reset Button, LED Button, Power Button
Input Power 100-240V~50/60Hz
Power Consumption 10W?max power consumption?
Dimensions ( W x D x H ) 6.4 x 3.0 x 2.6 in. (163 x 76.4 x 66.5mm)
Antenna 3 x external
WIRELESS FEATURES
Wireless Standards IEEE 802.11a/n/ac 5 GHz, IEEE 802.11b/g/n 2.4 GHz
Frequency 2.4GHz & 5GHz(11ac)
Signal Rate 5GHz:Up to 1300Mbps
2.4GHz:Up to 450Mpbs
Working Modes Range Extender/Access Point
Reception Sensitivity 5GHz?
11a 6Mbps:-93dBm@10% PER
11a 54Mbps: -76dBm@10% PER
11ac HT20 mcs8: -68dBm@10% PER
11ac HT40 mcs9: -64dBm@10% PER
11ac HT80 mcs9: -61dBm@10% PER
2.4GHz
11g 54M: -77dBm@10% PER
11n HT20 mcs7: -73dBm@10% PER
11n HT40 mcs7: -70dBm@10% PER
Wireless Modes Range Extender/Access Point
Wireless Functions Wireless Statistic
Concurrent Mode Boost Both 2.4G/5G WiFi Band
Access Control
LED Control
Domain Login Function
Wi-Fi Coverage
Wireless Security 64/128-bit WEP
WPA-PSK / WPA2-PSK
Transmission Power OTHERS
Certification CE, FCC, RoHS
Package Contents AC1750 Wi-Fi Range Extender RE450
Quick Installation Guide
Box Dimensions (W X D X H) 7.9 x 4.9 x 3.4in. (202x 125 x 86mm)
System Requirements Microsoft® Windows® 98SE, NT, 2000, XP, Vista or Windows 7, 8, 10, Mac® OS, NetWare®, UNIX® or Linux.
Environment Operating Temperature: 0°C~30°C (32°F~86°F)
Storage Temperature: -40°C~70°C (-40°F~158°F)
Operating Humidity: 10%~90% non-condensing
Storage Humidity: 5%~90% non-condensing
For additional version information, please go to the support page.
Maximum wireless signal rates are the physical rates derived from IEEE Standard 802.11 specifications. Actual wireless data throughput and wireless coverage are not guaranteed and will vary as a result of 1) environmental factors, including building materials, physical objects, and obstacles, 2) network conditions, including local interference, volume and density of traffic, product location, network complexity, and network overhead, and 3) client limitations, including rated performance, location, connection quality, and client condition.
The product may not be compatible with routers or gateways with firmware that has been altered, is based on open source programs, or is non-standard or outdated.
