The TP-Link 8-Port 10/100Mbps Desktop Switch with 4-Port PoE provides an easy and affordable way to expand your wired network with Power over Ethernet (PoE) capabilities. It features 8 auto-negotiation RJ45 ports with 4 PoE-enabled ports that can power and connect PoE-compatible devices like IP cameras, VoIP phones, and wireless access points.
Specifications
Product code: TL-SF1008LP
Description: TP-Link 8-Port 10/100Mbps Desktop Switch with 4-Port PoE
8× 10/100 Mbps RJ45 Ports (Ports 14 support 802.3af PoE)
AUTO Negotiation
AUTO MDI/MDIX
Network Media
10BASE-T: UTP category 3, 4, 5 cable (maximum 100m)
EIA/TIA-568 100 STP (maximum 100m)
100BASE-TX: UTP category 5, 5e cable (maximum 100m)
EIA/TIA-568 100 STP (maximum 100m)
Fan Quantity Fanless
Physical Security Lock Yes
External Power Supply External Power Adapter (Output: 53.5 V DC / 0.81 A)
Packet Forwarding Rate 1.1904 Mpps
PoE Ports (RJ45)
Standard: 802.3 af compliant
PoE Ports: Ports 14
Power Supply: 41 W
Mac Address Table 2K
Jumbo Frame 2 KB
Switching Capacity 1.6 Gbps
Dimensions ( W x D x H ) 6.7 × 3.9 × 1.1 in (171 × 98 × 27 mm)
Max Power Consumption
2.2 W (220 V/ 50 Hz. no PD connected)
47.1 W (220 V/ 50 Hz. with 41 W PD connected)
Max Heat Dissipation
7.5 BTU/h(no PD connected)
160.61 BTU/h(with 41 W PD connected)
Transmission Method Store-And-Forward
Advanced Functions
Compatible With IEEE 802.3af Compliant PDs
Extend Mode Button (Ports 14)
Priority Mode Button (Ports 12)
Mac Address Auto-Learning and Auto-Aging
IEEE802.3x Flow Control for Full-Duplex Mode and Backpressure for Half-Duplex Mode
