A solar charger gathers energy from your solar panels, and stores it in your batteries. Using the latest, fastest technology, SmartSolar maximises this energy-harvest, driving it intelligently to achieve full charge in the shortest possible time. SmartSolar maintains battery health, extending its life.
The SmartSolar charge controller will even recharge a severely depleted battery. It can operate with a battery voltage as low as 0 Volts, provided the cells are not permanently sulphated or otherwise damaged.
By constantly monitoring the voltage and current output of your solar (PV) panels, MPPT technology ensures that every drop of available power is rinsed out of your panels, and harvested for storage. The advantage of this is most noticeable when the sky is partially clouded, and light intensity is constantly changing.
Remotely control and monitor the extensive features of your SmartSolar MPPT charger with built-in Bluetooth by pairing it with your smartphone or other device via VictronConnect.
The intelligent Load output function prevents damage caused by running batteries 'flat'. You can configure the voltage at which SmartSolar disconnects a load - thereby preventing excessive drain on your batteries. And here's the clever bit: SmartSolar will attempt a 100% recharge every day. If it can't - during periods of poor weather - it raises the disconnect voltage, daily, until it achieves success. We call this feature BatteryLife because it maintains the health, and extends the life of your battery.
Features
Bluetooth Smart built-in
Ultra-fast Maximum Power Point Tracking (MPPT)
Load Output
Battery Life: intelligent battery management
Programmable battery charge algorithm
Day/night timing and light dimming option
Internal temperature sensor
Fully discharged battery recovery function
Specifications
Battery voltage (auto select): 12/24V
Rated charge current: 15A
Nominal PV power, 12V: 220W
Nominal PV power, 24V: 440W
Max. PV short circuit current: 15A
Automatic load disconnect: Yes
Max. PV open circuit voltage: 75V
Peak efficiency: 98%
Protection: Output short circuit / Over temperature
Protection category: IP43 (electronic components), IP22 (connection area)
What's in the box
- 1 x Victron Energy SmartSolar MPPT 75/15 Solar Charge Controller
