Vishay (MKT1813510255G) General Purpose Film Capacitor, Metallized PET

General Purpose Film Capacitor, Metallized PET, Axial Leaded, 1 µF, ± 10%, 160V, 250 VProduct InformationDielectric Type: Metallized PETCapacitor Case / Package: Axial LeadedCapacitance: 1µFCapacitance Tolerance: ± 10%Voltage(AC): 160VVoltage(DC): 250VCapacitor Mounting: Through HoleCapacitor Terminals: PC PinHumidity Rating: GRADE II (Test Condition A)Lead Spacing: -Product Length: 26.5mmProduct Width: -Product Height: -Product Range: MKT1813Operating Temperature Min: -55°COperating Temperature Max: 100°CQualification: -Product OverviewThe MKT1813510255G is an axial leaded DC Film Capacitor with polyester filmdielectric and metallised electrodes. The MKT1813 series film capacitor hastinned wire leads. It assists energy conversion while providing low losses, highefficiency and long life. For general purpose applications of DC-filtering,coupling, bypassing timing and interference suppression on low-voltage circuits.It is used for low building height applications. The electrodes of metallisedfilm capacitor consist of an extremely thin metal layer (0.02 to 0.1µm) that isvacuum deposited either onto the dielectric film or onto a carrier film. Theopposing and extended metalized film layers of the wound capacitor element areconnected to one another by flame spraying different metals to the end-faces.The metal spraying process is also known as schooping. The terminals areconnected to the end-faces by means of welding or soldering.Flame-retardant epoxy resin sealed plastic-wrapped encapsulationHigh volume efficiencySelf-healing propertiesApplicationsPower Management, Clock & Timing
