WESTKEN - 35kva Econofoot EF-35 Spot welder

35kva Econofoot EF-35

. This machine is our 35kva "Econofoot" and is based on the following basic specification.

1) Model Name "Econofoot 35kva" EF-35 which is a 380v @ 50hz, 35kva machine rated at 20% duty cycle machine.
2) Capable welding diameters 2.00mm mild steel to 2.00mmdia mild steel.
3) Foot lever operated welding head with spring follow-up
4) 50mm brass arms, 25mm water cooled tip holder, MT2 16mm CuCrZr welding tips.
5) The machine is water cooled and will need a minimum of 20l/min flow through the machine. (Please note cooling unit is sold separately)
6) Digital weld and heat timers control operating through a semipack thyristor system.
7) Water cooled transformer.
8) Foot print 400mm x 1015mm x 1510mm
