Connect 502USB 5-Channel Mixer
The Wharfedale Pro Connect 502USB is a compact mixing desk with massive capabilities. If you need a portable mixing desk and you do not want to sacrifice space for connections we have managed to condense ample inputs, outputs, and other digital features into a slim, small-footprint USB mixer which is at home in the studio as it is the road.
Key Features
- 5 Total Inputs (1 x XLR / 6.3mm Jack, 2 x twin 6.3mm jack)
- 2 x 6.3mm jack outputs, headphone
- Studio grade phantom power XLR
- 16-bit / 48kHz built-in USB audio interface
- Playback and record via USB audio interface
- Headphone output
- Pan / Balance control
- Clip LED display
- Ideal for home studio recording and live use
- Slimline profile for portability and to fit in gig bags
Leave The Larger Mixer Behind
The connect series is the ideal companion for small-scale live performances and discreet sound installations where there simply isn't space for a full-scale mixing desk. While packing a wealth of features for mixing and recording it does so with a small footprint. The use of rotary controls as opposed to larger linear faders means space is saved to fit the mixer into small spaces even including guitar gig bags, yet the textured rotary pots operate with a suitable resistance so EQ and level controls can be pin-pointed with accuracy.
Small Size, Studio Sound
The Connect 502USB features a studio-grade XLR / Jack input with phantom power and two additional stereo channels. This makes the mixing desk particularly well suited to singer-songwriter musicians who maybe use their vocals combined with a guitar and backing tracks.
USB Audio Interface
With a built-in USB audio interface, this latest series enables a stereo in/out which can be used for playback of audio files from your PC or Mac and can also record the master output of your mixing desk. 16-bit / 48 kHz recording ensures CD quality for your audio, whether working in a live or studio environment.
Wharfedale Pro Affordability and Quality
As with all Wharfedale pro products, the Connect Series are competitively priced yet maintain the essentials of a high-quality mixing desk. High headroom and low noise operation ensure a professional sound and integration with any sound system.
General Specifications
- Channels: 5
- Inputs: 1 x XLR, 5 x 6.3mm jack
- Outputs: 2 x 6.3mm jack
- Headphone Outputs: 6.3mm Jack
- EQ: 2-Band
- Phantom Power: Yes
- Signal-to-noise Ratio: >78dB ± 5dB @ Max Gain
- Frequency Response: 20Hz — 20kHz ± 2dB
- Display: Dual 4-Segment LED
- Dimensions (HxWxD): 50.9mm x 143mm x 183.8mm
- Weight: 0.64kg
