Everyone Loves Bass!
That is exactly why we have created the T-Sub-AX series of active subwoofers.
The internal Class D amplifier delivers huge output power into the custom Wharfedale Pro LF driver to produce extreme subs and low-end pressure into any system. Built for big bass, the plywood-constructed cabinet is rock solid and is protected in durable black paint.
You'll not only 'feel' a T-SUB-AX, but you will also see it! A new illuminated WP logo badge subtly glows and adds to the overall on-stage "power" of the new T-Sub.
T-Sub-AX models are designed to be the perfect companion for a Typhon or a Titan active loudspeaker. Hold on to your socks! T-Sub-AX is going to blow them off!
Key Features
- 18" Active Sub
- Quad Layer Drive
- 3.0" Voice Coil
- 900 W Continuous
- 1800 W Peak
Perfect Pairing
T-Sub-AX models have been designed to be the perfect partner for Wharfedale Pro plastic active loudspeakers. Used with a Tourus, a Titan or our flagship Typhon models, a T-Sub-AX completes the system — bringing new levels of bass to the setup.
Protect The Bass
Protective optional soft covers are available for all T-Sub-AX Active Subwoofers.
With easy access to both carry handles and soft protective padding, the T-Sub soft covers are simple to put on and simple to remove — making setup and breakdown easy.
General Specifications
- Model Name: T-Sub-AX18B
- System Type: Active 18" Subwoofer
- Frequency Response (+/-3 dB): 40 Hz-200 Hz
- Frequency Response (+/-10 dB): 35 Hz-250 Hz
- Sensitivity @ 1 w / 1 meter: 97 dB
- Maximum SPL (peak @ 1 meter) Half space: 133 dB
- Low-Frequency Transducer
- Size (mm / inches): 470mm / 18"
- Coil Size mm / inches): Quad layer 3.0
- Impedance: 4
- Amplifier
- Low-Frequency Power Amplifier (Class D): 900 W Continuous / 1800 W Peak
- Crossover Frequency: LPF 80-200 Hz (adjustable)
- Controls
- Amplifier Protection: Yes
- Power On Protection: Power switch on / off mute
- Thermal Protection: Amplifier shutdown, auto reset
- Drive Protection: Yes
- DC Protection: Yes
- Short Protection: Yes
- Limiter Indicator: Red LED
- Input Type: Balanced
- Input Connector: (2) socket XLR
- Input Impedance: 47 k Balanced
- Input Sensitivity: -10 dBu
- Link Output Connector: (2) pin XLR
- Polarity Switch Selection: 0° / 180°
- AC Power Details
- Power Supply: SMPS
- AC Power Options: 100 V-120 V and 200 V-240 V
- Power Indicator: Green (back) / Blue logo (front)
- Enclosure
- Enclosure Material: 15mm Plywood
- Colour: Black
- Paint: Tough-Tone
- Grille: 1.5mm Steel
- Pole Mount (Top): 35mm
- Dimensions (WxDxH): 528mm X 638.8mm X 650mm / 20.6" X 25.2" X 25.6"
- Weight: 36.5kgs / 80.5lbs
