Description:

This module is a motor control module which can be used to control ordinary DC motor, smart car motor, etc. Compact size, light weight.

Features:

Can be used to control ordinary DC motor, smart car motor, etc.
Reversible control and PWM speed control.
High speed switch design.
Ultra low internal resistance, low heat.
Operating voltage: DC 5-12V; operating current: 0A-30A(Max)/each channel.

Specifications:

Operating Voltage: DC 5-12V
Standby Current: <30mA&pm;5mA
Current: 0A-30A(Max)/each channel
PWM Mode: Duty Cycle: 0-98%; Frequency: General Motors: 16kHz; Coreless Motor: 80kHz; TEC: 500Hz-80kHz
Input Voltage Level: Low:0-0.5V; High: 2.5V-13V(typical drive level: 3.3V, 5V, 12V)
Current Sampling: CT Pin Output Voltage(V)=Current(A) x 0.155
Item Size: 6.2 x 5.3 x 1.8cm / 2.44 x 2.08 x 0.71inch

Package included:

1 x DC 5-12V 30A dual channel motor control module
