Battery Parameters
Compatible Battery Type: Lead-acid / Lithium
Nominal Battery Voltage: 48VDC
Battery Voltage Range: 40VDC-60VDC
Maximum Charge / Discharge Current: 210A
Maximum Charge / Discharge Power: 10 000W
DC PV Input
Max DC Input for Single MPPT: 12 000W / 7 000W / 7 000W
Maximum PV Input: 16 000W
DC Input Voltage Range: 100VDC-600VDC
Nominal DC Input Voltage: 360VDC
Full Power MPPT Voltage Range: 210VDC-500VDC
Maximum DC Input Current: 25A / 15A / 15A
MPPT Number / Strings per MPPT: 3(2/1/1)
AC Output (Grid)
Nominal Power: 10 000W
Nominal AC Voltage: 240VAC
Operating Voltage Range: 180VAC-270VAC
Maximum Continuous AC Current: 41.6A @ 240VAC
Nominal AC Frequency: 50Hz / 60Hz
UPS Output (With Battery)
UPS Max Output Power: 10 000W
UPS Nominal Output Voltage: 240VAC
UPS Nominal Output Frequency: 50Hz / 60Hz
UPS Nominal Output Current: 41.6A @ 240VAC
Peak Power: 14Kw 10Min / 16Kw 5 Min / 20Kw 500ms
Switching Time: <20ms
Environment Limit
Ingress Protection: IP65
Operating Temperature Range: -25C to +60C
Cooling: Fan
Communication: RS485 / WIFI / CAN
