For core drills with 19 mm Weldon shank
Stable drill guide due to the long and especially deep mounted quill holder
Device is earthed and double insulated, making it ideal for the job site
High magnetic holding force
High quality construction
The coolant is passed through the drill
Quick-action adapter for easy changing of the core drills
Conversion from core drilling to full drilling in just a few steps
Safe and reliable function
A speed
Quick release chuck
1,100 watt motor
Max. Magnetic holding force of 15,000 N Collet
Spindle M 24
Drill Weldon 3/4"
Core drills
Core drills Ø max. with manual feed 35 mm
Max. drilling depth core drilling with manual feed 50 mm
Dimensions and weights
Length approx. 280 mm
Width/depth approx. 260 mm
Height approx. 395 mm
Weight approx. 12 kg
Electrical Data
Drive motor output 1,1 kW
Supply voltage 230 V
Mains frequency 50 Hz
Full drills
Drill Ø max. full drilling mounted with adapter & chuck 13 mm
Drilling depth max. full drilling mounted with adapter & chuckBohrtiefe max. 110 mm
Magnet
Holding force 15000 N
Magnet base length 165 mm
Magnet base width 80 mm
Speed range
Speed(s) under load 330 min¯¹
VPE 1
