Multicomp Pro (MC000023) Wire-To-Board Terminal Block, 3.81 mm, 8 Ways

Wire-To-Board Terminal Block, 3.81 mm, 8 Ways, 26 AWG, 16 AWG, ScrewProduct OverviewThe MC000023 is a 8-way 10A wire-to-board Terminal Block with tin-plated brassterminal, green polyamide 66 insulating body, nickel-plated brass cage clamp andsteel nickel-plated screw. It has screw wire connection and through-holeright-angle block orientation.2000MR at 500VDC Insulation resistance (Maximum)-55 to 105°C Operating temperature rangeApplicationsIndustrialProduct InformationPitch Spacing: 3.81mmNo. of Positions: 8WaysWire Size AWG Min: 26AWGWire Size AWG Max: 16AWGConductor Area CSA: -Wire Connection Method: ScrewRated Current: 10ARated Voltage: 300VBlock Orientation: Through Hole Right AngleProduct Range: -
