POOL PUMP AND MOTOR 0.75KW EARTHeCO (EQ/EQUE)

HAVE A LOOK AT THE NEW AQUAMAX COMPETING RANGE OF POOL PUMPS



The EartheCo Pump And Motor 0.75kW or commonly known as an EQ/EQUE Pump is a self-priming, centrifugal pump with closed vane impellor is designed to give you years of trouble-free operation. The EartheCo Pump is fitted with a leaf trap strainer/basket, mechanical shaft and squirrel cage induction motor, with heavy duty ball bearings. Fitted with unions and threaded on the inside of the casting, the inlet and outlet installations are carried using the latest technology.

The EartheCo 0.75kW model is suitable for an Aquamax/Aquaflo, EartheCo or Quality 2 or 3 bag sand filter and comes with a 2-year manufacturing defects warranty.

Pump Specifications:
Self Priming, Centrifugal Type Pumps with closed vane impellers.
— 0.60kW K71
— 0.75kW K71
— 0.75kW K80
— 1.10kW K80
• Fitted with leaf trap strainers, mechanical shaft seals and squirrel cage induction motors with heavy duty ball bearings.
The pump type and serial number are on a nameplate attached to the motor shroud, and the motor data is in a nameplate attached to the side of the motor

INSTALLATION INSTRUCTIONS

We recommend that the pump is installed by a qualified pool professional or electrician.

The pump is a self-priming pump, which can be installed above or below water level, if you choose to go below, be sure to connect a control valve on your suction pipe between the pool weir/skimmer and the pump, which will prevent your pump being flooded when you open the lid to clean the pump leaf basket.

Do not over tighten fittings into the inlet and outlet of the pump. Position pump on a flat level surface not exposed to flooding, as the pump motor is not waterproof.

Electrical connection should be done by an electrician, be sure to earth the motor. Pump should be installed in a weatherproof and well ventilated enclosure away from all chemicals. Before starting the motor, open the lid of the pump and add water to cover the basket, replace lid and tighten by hand. Never run the pump dry without water, and clean the pump leaf basket regularly.
