Solar Inverter - 10.2kW 2 x PV input, DUAL AC OUTPUT, 48V, Pure sine-wave, STAND ALONE Inverter.

10.2kW, 2 x PV inputs , DUAL AC OUTPUT, 48V, Pure sine-wave  STAND ALONE Inverter with RGB (Status) lights. Cannot be parallel connected.

User Manual available here

IP Rating:

• IP20
• Not recommended for installation location with high humidity
• If the inverter needs to be installed close to the ocean please make use of a dehumidifier.

Features:

• RGB lights (red, blue, violet) for Inverter modes : Utility, Battery & Solar.
• 2 x AC outputs (MAIN & 2ND)
• 2 x PV inputs working off single MPPT-controller.
• Smart battery charger design for optimized battery performance.
• Configurable AC/Solar charge priority.
• Cold start function.

Max Watt Output:

• Continuous: 10.2kW
• Surge (5 seconds) : 20.4kW

Output and Charging Source Settings:

• Utility-Solar-Battery, Solar-Utility-Battery, Solar-Battery-Utility

• Solar only: 160A (maximum)
• Grid only: up to 140A
• MAIN output/load = 10.2kw
• 2ND output/load = 2.04kW - 7.14kW

Solar input requirements:

• 90 - 450Vdc solar input is the optimal working range for these inverters.


Monitoring & Setting:

• LCD screen & RGB LED's
• Wifi module (optional) available. Monitoring via Smart ESS app.

Expansion: Single Inverter

• PV Panels maximum: 10200W, 5400W per input.
• Max 18A per PV input.

• Peak Efficiency: 98%


Expansion: More Inverters

• Can only be used as single inverter.

 Physical dimensions

• 618 x 463 x 205mm (boxed).
• 16KG

What's in the box

• Inverter
• User manual

• MC4 Connectors x 2

IMPORTANT: THE CORRECT SETTINGS ON THE INVERTER WILL AID IN ENSURING OPTIMAL BATTERY LIFE.

Warranty:

12 Months Warranty

Please take note of the full warranty terms and conditions.
