Vishay (BFC233620474) Safety Capacitor, Metallized PP, 0.47 µF, ± 20%

Safety Capacitor, Metallized PP, Radial Box - 2 Pin, 0.47 µF, ± 20%, X2, ThroughHoleProduct InformationDielectric Type: Metallized PPCapacitor Case / Package: Radial Box - 2 PinCapacitance: 0.47µFCapacitance Tolerance: ± 20%Suppression Class: X2Voltage Rating Y: -Capacitor Mounting: Through HoleVoltage Rating X: 310VACdv/dt Rating: 150V/µsHumidity Rating: GRADE II (Test Condition A)Lead Spacing: 22.5mmOperating Temperature Min: -55°COperating Temperature Max: 110°CProduct Range: MKP3362Series Name: MKP3362Qualification: -Product OverviewThe BFC233620474 is a radial leaded Interference Suppression Film Capacitor withpolypropylene film dielectric and metallised film electrodes. The MKP336 2 X2series film capacitor has tinned wire leads and mono construction. It assistsenergy conversion while providing low losses, high efficiency and long life. X2capacitor provide protection for applications where pulses up to 2.5kV areexpected.UL94V-0 flame-retardant epoxy resin sealed plastic case encapsulation310VAC at 50 to 60Hz Rated AC voltageApplicationsPower Management, RF Communications
