Vishay (BFC237321685) General Purpose Film Capacitor, Metallized PET

General Purpose Film Capacitor, Metallized PET, Radial Box - 2 Pin, 6.8 µF, ±10%, 63 V, 100 VProduct InformationDielectric Type: Metallized PETCapacitor Case / Package: Radial Box - 2 PinCapacitance: 6.8µFCapacitance Tolerance: ± 10%Voltage(AC): 63VVoltage(DC): 100VCapacitor Mounting: Through HoleCapacitor Terminals: PC PinHumidity Rating: GRADE II (Test Condition A)Lead Spacing: 27.5mmProduct Length: 21mmProduct Width: 31mmProduct Height: 21mmProduct Range: MKT373Operating Temperature Min: -55°COperating Temperature Max: 105°CQualification: -Product OverviewThe MKT373 series DC Film Capacitor with polyester film dielectric andmetallised electrodes. It has tinned wire leads, flame retardant plastic caseand epoxy resin. It is suitable for blocking and coupling, bypass and energyreservoir.Green productUL94V-0 Flammability rating15 to 27.5mm Lead pitch0.047 to 15µF Capacitance range (E12 series)±10% and ±5% Capacitance tolerance availableApplicationsIndustrial
