Wire-To-Board Terminal Block, 5.08 mm, 8 Ways, 28 AWG, 12 AWG, 2.5 mm², ClampProduct OverviewThe 236-408 is a 8-pole grey PCB Terminal Strip with front/side-entry wiring.This terminal strip has tin-plated electrolytic copper contacts and a polyamide6.6 insulator. It accepts 28 to 12AWG wire size.Cage Clamp connection methodOperating tools for factory wiring45° Connection angle permits a wide range of uses and wiring optionsUL94V-0 Flammability ratingLimit temperature range from -60°C to 105°CWeight is 7g, rated voltage (III/2) is 320V and nominal current of 24AFlammability rating meets UL94 V-0 and meets IEC/EN 60664-1 specificationsSuitable for wire size ranging from 28AWG to 12AWGTwo in-line solder pins/poleApplicationsIndustrialProduct InformationPitch Spacing: 5.08mmNo. of Positions: 8WaysWire Size AWG Min: 28AWGWire Size AWG Max: 12AWGConductor Area CSA: 2.5mm²Wire Connection Method: ClampRated Current: 24ARated Voltage: 320VBlock Orientation: Through Hole 45°Product Range: 236
